Products
Servo Motor Wire Saw DSME-200A
Specifications
| Specifications | ||
|---|---|---|
| Model name | DSME-200A |
|
| Power source | Three phase 400/440V 50/60Hz | |
| Motor power | 20kW | |
| Rated current | 32A | |
| Output shaft max. torque | 276N-m（Boost mode） | |
| Max. rotation speed | 850min-1 | |
| Wire diameter |
10～11mm
|
|
| Wire strage | 12.4m | |
| Drive pulley travel | 1,150mm | |
| Size W×L×H | 1,904×543×2,076mm | |
| Weight （Excluded control box and cable） |
180kg | |
